PN63～160, DN40～600
Design and manufacture: DIN3352
Face to face: DIN3202-F7, EN558-1
End flange Dimensions: DIN2546(PN63), DIN2547(PN100), DIN2548(PN160), EN1092-1
Pressure test: DIN3230, EN12266-1
The size of serial, valve connecting flange can be design according to customers’ requirement.
|
|
|
 |
Standard Material Specifications
|
NO.
|
Part Name
|
Material
|
NO.
|
Part Name
|
Material
|
|
1
|
Body
|
GS-C25+13Cr
|
11
|
Nut
|
A194 2H
|
|
2
|
Wedge
|
GS-C25+13Cr
|
12
|
Gland
|
GS-C25
|
|
3
|
Stem
|
A182 F6
|
13
|
Yoke
|
GS-C25
|
|
4
|
Nut
|
A194 2H
|
14
|
Bearings
|
Alloy Steel
|
|
5
|
Bolt
|
A193 B7
|
15
|
Nipple
|
Brass
|
|
6
|
Gasket
|
Graphite
|
16
|
Stem Nut
|
A439 D2
|
|
7
|
Bonnet
|
GS-C25
|
17
|
Retaining Nut
|
Carbon Steel
|
|
8
|
Packing
|
Graphite
|
18
|
Handwheel
|
A536
|
|
9
|
Pin
|
Carbon Steel
|
19
|
Nut
|
Carbon Steel
|
|
10
|
Gland Eyebolt
|
A193 B7
|
20
|
Grub Screw
|
Carbon Steel
|
Dimensions(mm)
|
PN63
|
|
DN
|
40
|
50
|
65
|
80
|
100
|
125
|
150
|
200
|
250
|
300
|
350
|
400
|
500
|
600
|
|
L
|
240
|
250
|
290
|
310
|
350
|
400
|
450
|
550
|
650
|
750
|
850
|
950
|
1150
|
1350
|
|
H
|
385
|
440
|
480
|
525
|
625
|
740
|
810
|
1045
|
1260
|
1490
|
1630
|
1840
|
2260
|
2720
|
|
W
|
180
|
200
|
220
|
250
|
280
|
400
|
450
|
500
|
500
|
600
|
650
|
700
|
800
|
900
|
|
PN100
|
|
DN
|
50
|
65
|
80
|
100
|
125
|
150
|
200
|
250
|
300
|
350
|
400
|
|
L
|
250
|
290
|
310
|
350
|
400
|
450
|
550
|
650
|
750
|
850
|
950
|
|
H
|
460
|
500
|
550
|
660
|
765
|
850
|
1090
|
1310
|
1550
|
1710
|
1920
|
|
W
|
220
|
250
|
280
|
300
|
400
|
450
|
500
|
550
|
600
|
650
|
700
|
|
PN160
|
|
DN
|
50
|
65
|
80
|
100
|
125
|
150
|
200
|
|
L
|
250
|
290
|
310
|
350
|
400
|
450
|
550
|
|
H
|
460
|
500
|
550
|
660
|
765
|
850
|
1090
|
|
W
|
220
|
250
|
280
|
300
|
400
|
450
|
500
|
|
